202 Stainless Steel Fittings – High-Strength, Cost-Smart Austenitic Solution
Meta Description (142 characters):
202 stainless steel fittings deliver 304-like strength at 40% lower cost. Mirror polish, excellent formability. Global shipping. Instant quote.
Premium 202 stainless steel fittings with brilliant mirror-polished surface
Introduction
Searching for stainless fittings that outperform 201 in strength yet undercut 304 in price? 202 stainless steel fittings (UNS S20200) are your answer. This nitrogen-strengthened, manganese-rich austenitic grade delivers 30–40 % higher yield than 201 while slashing material cost by 35–45 % versus 304. From mirror-polished handrail elbows to deep-drawn tee reducers, 202 stainless steel fittings keep high-speed presses running and architectural budgets healthy. Discover why leading 202 stainless steel fittings suppliers worldwide are switching to this lean-alloy powerhouse for decorative, structural and light-duty fluid systems.
What are 202 Stainless Steel Fittings? (UNS S20200)
202 stainless steel fittings are nitrogen-strengthened, manganese-rich austenitic components that maintain full non-magnetic properties and excellent formability. The balanced chromium (17–19 %) and manganese (7.5–10 %) content provides urban corrosion resistance, while nitrogen (≤0.25 %) boosts yield strength above 350 MPa—far exceeding 201-cost ratios. Compared with 201, 304, or 316, 202 stainless steel properties include better work-hardening rate and price stability, making them the first choice for cost-conscious projects that still demand 304-like aesthetics and strength.
Chemical Composition (% by mass, balance Fe)
| Element | 202 | 304 |
|---|---|---|
| C | ≤0.15 | ≤0.08 |
| Si | ≤0.75 | ≤0.75 |
| Mn | 7.5–10.0 | ≤2.0 |
| P | ≤0.06 | ≤0.045 |
| S | ≤0.03 | ≤0.03 |
| Cr | 17.0–19.0 | 18.0–20.0 |
| Ni | 4.0–6.0 | 8.0–10.5 |
| N | ≤0.25 | ≤0.10 |
Product Range & Technical Specifications
- Types: 90°/45° Elbow, Equal/Reducing Tee, Concentric/Eccentric Reducer, Cross, End Cap, Stub End, Full/Half Coupling, Union, Threaded (NPT/BSP), Socket-weld, Welded butt-weld
- Standards: ASME B16.9, B16.11, MSS SP-43, SP-83, SP-95, EN 10253
- Size Range: Seamless 1/2"–24", Welded up to 48"; Threaded 1/8"–4"
- Wall Thickness: Sch5s, Sch10s, Sch40s, Sch80s, Sch160, XXS
- Surface Finish: Pickled, polished 180–600 grit, brushed, sandblasted
- Threads: ISO, NPT, BSPP, BSPT, DIN 2999
Common Dimensions & Pressure Ratings
| Nominal Size (in) | OD (mm) | Sch | Rating (bar) | Standard |
|---|---|---|---|---|
| 1/2 | 21.3 | 10S | 18 | ASME B16.9 |
| 1 | 33.7 | 40S | 50 | EN 10253 |
| 2 | 60.3 | 80S | 68 | MSS SP-43 |
| 4 | 114.3 | 10S | 15 | ASME B16.9 |
| 6 | 168.3 | 40S | 40 | EN 10253 |
Mechanical Properties (ASTM A403)
| Property | Value |
|---|---|
| Density | 7.9 g/cm³ |
| Tensile Strength | ≥650 MPa |
| Yield Strength (0.2 %) | ≥350 MPa |
| Elongation | ≥40 % |
| Hardness HRB | ≤95 |
| Impact Energy (Charpy V) | ≥60 J @ 20 °C |
Full assortment of 202 stainless steel fittings – elbows, tees, reducers, and caps
Key Advantages of 202 Stainless Steel Fittings
- 30–40 % Lower Cost than 304 Fittings – Stable Mn/Ni ratio shields you from LME nickel spikes; lower 202 stainless steel fittings price.
- Higher Yield and Tensile Strength than 201 Grade – 350 MPa yield allows thinner walls without deformation.
- Excellent Cold Forming and Deep Drawing Capability – High n-value achieves complex reducer shapes without edge cracking.
- Good Weldability and Bright Polished Appearance – 600G mirror finish achieves luxury reflectivity for decorative elbows.
- Price-Stable Due to Lower Nickel Content – Large inventory keeps lead times short and budgets predictable.
Wide Applications
- Architectural Handrails & Balustrades: Mirror-polished 202 stainless steel fittings for handrail – elbows, tees, flanges for luxury balconies and shopping malls.
- Furniture & Interior Decoration: Square tube connectors, decorative caps, table-leg bases with brushed HL finish.
- Food Processing Support Structures (Non-Sanitary): Conveyor frame corners, display racks, non-acidic ingredient transfer.
- Water Supply & Low-Pressure Pipelines: Urban cold-water lines, greenhouse irrigation, fire-sprinkler headers where chloride <50 ppm.
- Automotive & Two-Wheeler Exhaust Systems: Mandrel-bent elbows and reducers; 350 MPa yield allows down-gauging for weight savings.
- Greenhouse Frames & Fencing: Pickled round fittings for vineyard posts, deer fencing, solar-panel racking.
- General Engineering & Structural Projects: Sanitary unions, quick-release clamps, adjustable elbows for exhibition booths.
Mirror-polished 202 stainless steel fittings installed in high-end commercial handrail
Manufacturing Process & Quality Assurance
- Electric-Arc Furnace + AOD Refining – Exact chemistry, ultra-low inclusion content.
- Continuous Casting & Forging – 200 mm billets for uniform grain structure.
- Hot Forging & Extrusion – Reducer tees, elbows at 1,100 °C under protective atmosphere.
- Cold Forming & Sizing – Mandrel-bent elbows to ±1° angle tolerance; 600G mirror polish optional.
- Solution Annealing – 1,050 °C in pure H₂ for restored corrosion resistance and bright BA finish.
- Machining & Threading – CNC lathes achieve ±0.02 mm thread accuracy; NPT, BSP, ISO threads.
- QC Testing – Spectrometer, tensile, flattening, thread gauge, 100 % PMI ensure every 202 stainless steel fitting meets specification.
Packaging & Shipping Standards
- Individual Protection: Plastic caps on threads, PE sleeve on polished surfaces.
- Outer Packaging: 5-ply export carton + wooden crate, fumigation-free IPPC stamp.
- Bundling: Hexagonal bundle with 4–8 steel straps, 3×3 wooden sleepers for large fittings.
- Marking: Heat number, size, rating, standard, production date on outer carton.
- Shipping: 20 ft or 40 ft container, average 22 tons payload; same-day loading on stock items.
Why Choose Our 202 Stainless Steel Fittings?
✅ Factory-Direct Pricing & Massive Stock – Eliminate trader margins; lock 202 stainless steel fittings price for 30 days.
✅ Complete Size & Type Availability – 1/8"–48", all pressure classes, seamless & welded; 5,000 t ready for immediate dispatch.
✅ OEM & Custom Fabrication Service – Laser cutting, special angles, private labeling.
✅ Third-Party Inspection & Certificates – EN 10204 3.1 MTC, SGS, BV, ISO 9001 supplied free.
✅ Fast Worldwide Delivery & Export-Grade Packaging – 5-day FOB to 120+ ports; DDP available.
Individually protected and boxed 202 stainless steel fittings ready for global shipment
Frequently Asked Questions
Q1: What is the difference between 202 and 304 stainless steel fittings?
A: 202 uses manganese and nitrogen to replace most nickel, giving 30–40 % lower cost and similar urban corrosion resistance, but slightly less pitting resistance than 304.
Q2: Are 202 stainless steel fittings food safe?
A: Yes, they meet FDA and GB 4806.9 for non-acidic food contact; widely used for display racks and conveyor frames.
Q3: Can 202 fittings be used outdoors?
A: Suitable in urban or low-chloride environments; for coastal salt-spray, 316 is recommended.
Q4: Is 202 stainless steel magnetic?
A: Essentially non-magnetic in annealed condition; permeability <1.005 even after cold forming.
Q5: Why are 202 fittings much cheaper than 304?
A: Reduced nickel raw-material cost and more stable alloy pricing shield buyers from LME nickel volatility.
Q6: Can 202 fittings be welded with 308L or 309 filler?
A: Yes, ER308L is compatible; for color match use ER202 or ER309L.
Q7: Is 202 stronger than 201 stainless steel?
A: Yes, 202 offers ~15 % higher yield strength and better corrosion resistance due to higher chromium and nitrogen content.
Call to Action
Get Instant Quote for 202 Stainless Steel Fittings Now!
Huge stock, unbeatable price – Save up to 40% vs 304 fittings!
